Centreless Grinding Wheels

• A Centreless Wheel (Also known as Hubless Wheel,Orbital Wheel) is a wheel with no centre. The hub is actually almost as big as the wheel itself. The axle is hollow,following the wheel at very close tolerances. It work with help ofRegulating Wheel.
• Normal Speed: 25mps – 45mps.
• Application in following material: Axle, Bearings, Pin, Valve Steel, Engineering Files, Soft Steel, Hardened Steel, Alloys/M.S Steel, S.S Bright Bar, Cylinder Liner Etc.
• #PRODUCT RANGE:
• [table id=3 /]

Cylindrical Grinding Wheels

• Cylindrical Grinding is used to shape the outside of Job Work.It is having four essential actions:
  1. The work must be constantly rotating.
  2. The Grinding Wheel must be constantly rotating.
  3. The Grinding Wheel is fed towards and away from the job work.
  4. Either the job work or the Grinding Wheel is traversed with respect to the other.
• Speeds (SFPM) = 5000 m/min-12000 m/min (Since, SFPM = R.P.MXDiameterX0.262)
• Application in following Material : C.I, Soft Steel, Hardened Steel, H.S.S,Tungsten Carbide, Rubber Roll, General Purpose.
• #PRODUCT RANGE:
• [table id=4 /]

Roll Grinding Wheels

• Roll Grinding Wheel is a specialized from of cylindrical grinding and precision grinding of various kinds of rolls. Roll Grinding Wheels are used in the Re-Grinding , production grinding of roll for the steel, Brass, CU, AL, printing Paper and Textile Industries.
• #PRODUCT RANGE:
• [table id=5 /]

Crank Shaft Grinding Wheels

• Crank shaft grinding is the cylindrical grinding of the crank pin or Bearing by Plunge from method.
• Normal Speed: 33mps- 45 mps
• Application in following Material: Forged Steel Soft, Forged Steel Hard(Roughing), Forged Steel hard(Finishing), C.I(Roughing), C.I(Finishing), R-e-Grinding, SG(Iron), Heat treated Steel.
• #PRODUCT RANGE:
• [table id=7 /]

General Purpose Grinding Wheels

• General purpose Grinding Wheel is used on bench,floor stand and pedestal grinders.It is most economic and efficient in grinding of all steels.
• It is made of specially Brown Fused Alumina/Brown Aluminium Oxide, White Fused Alumina, Silicon Carbide(Green & Black) Abrasives mni eral that give rapid grinding action, cooler cutting, excellent finish and higher productivity.
• Speeds(SFPM): 4000m/min -6500m/min (Since,SFPM=R.P.MXDiameterX0.262).
• #PRODUCT RANGE:
• [table id=8 /]

Download Pdf
